Professional lifting bags PROFESSIONAL LIFT BAGS

These open bottom parachute shaped lifting bags with a single attachment point, which are our most versatile and easy to use, are indispensable in construction, heavy and light salvage and many offshore tasks.

The "inverted water drop" design facilitates maximum load capacity with the least weight, while tension is evenly distributed across the fabric surface.They are equipped with all necessary fittings and ready for immediate use.Each Subsalve USA lifting bag is tested before shipment.

• urethane coated nylon - highly strong and durable
• excellent abrasion resistance
• resistant to most petrochemicals substances
• UV resistant
• low maintenance and easy cleaning
• RF welded seams

Proprietary plunger drain valve - air control via a button on the top of the bag and a drawstring at the bottom. Air discharge from the top, next to or bottom of the lift bag to achieve the desired rate of ascent as well as a 1/4” NPT inflatable opening.

Under 2 tons

Multiple nylon lift straps sewn directly to the bottom of the lift bag to carry the load and provide a safe 6:1 working ratio.

2 tons and over

Designed with interchangeable heavy duty nylon lifting strap made into the bag shell to carry the load and provide a safe working ratio of 6:1.It features a 3/4” NPT inflation port with quick disconnect or cam lock and a 3/4” stainless steel ball valve for quick inflation.Air release.

Model Lift Capacity Diameter Overall Height Packaged Cubic Dimension Weight PF-1000 500kg 0.90m 1.44m .46m x .33m x .26m 7.7kg PF-2000 1000kg 1.13m 1.62m .51m x .38m x .29m 13.6kg PF-4000 2000kg 1.38m 2.41m .61m x .61m x .61m 22.7kg PF-6000 3000kg 1.56m 2.77m 1.04m x 1.04m x .21m 36.3kg PF-10000 4600kg 1.83m 2.95m 1.04m x 1.04m x .25m 47kg PF-12000 5500kg 1.79m 3.33m 1.04m x 1.04m x .31m 56.7kg PF-20000 10000kg 2.38m 4.10m 1.04m x 1.23m x .46m 86.2kg PF-40000 20000kg 3.07m 6.16m 1.04m x 1.23m x .62m 147.7kg PF-70000 35000kg 3.69m 6.77m 1.04m x 1.23m x .97m 186.9kg PF-100000 48500kg 4.22m 8.03m 1.02m x 1.27m x 1.37m 238kg

Each Subsalve USA lifting bag is tested prior to shipment.Custom sizes are available.All Subsalve USA products comply with IMCA D-016-AIRBAGS, ABS, U.S. Department of Defense Standards.
