Regulator ATOMIC M1 DIN 1.st

Atomic M1 - regulator first stage

Monel components are used inside the first stage to increase strength, corrosion resistance and for oxygen compatibility. Grade 316 stainless steel, Zirconium-plated brass and Titanium make up the mechanism of the second stage. The M1 metering valve body is Zirconium/Nickel plated brass and the seat pressure limiter is stainless steel.

The valve body is made of stainless steel.

Hard conditions are a challenge for us! Atomic engineers have created this model for the rigors of diving - both recreational and technical. The M1 extends the range of applications to any imaginable diving conditions, whether recreational or technical. Top and demanding divers appreciate the fact that the M1 meets all their needs on any dive profile. The M1 is based on the same fundamentals as the renowned T2x and B2 models.

Specifications

• The regulator is 100% oxygen compatible from the factory and can be used for pressures up to 300bar
• The body of the first stage is made of chrome plated brass, Monel is used for the key parts inside
• First stage with high flow piston and Jet Seat technology
• Freezing protection implemented by separating the medium pressure chamber from the outside environment also prevents the ingress of dirt or sand to sensitive parts
• First stage outputs: 2 HP fixed / 5 LP on swivel head
